Ocean Leopard is a legend, being one of the best known boats in both the Solent and Antigua, having smashed and held the Round the Island Record for several years in the early 90’s and other numerous records including Line Honours in the Round Britain race in the 90s. She has been converted to a comfortable cruising and charter boat but she is still one of the fastest GRP cruising boats out there witnessed by her class line honours win in the 2016 Round the Island Race - First Classic Racing boat across the line, winning the Field Barnacle Cup. Despite being quick she can be comfortably handled for cruising by a small amateur crew. She has cruised the World with many Atlantic crossings from the Med to Caribbean, Fiji to South Pacific Polynesia, Australia to New Zealand and Hawaii. She is equipped with a detachable hard top for comfortable Ocean Cruising. Please call the Ancasta Port Solent team on 02392 373 300 or email email@example.com for more information and to make an appointment to view.The boat further offers amazing opportunities for Charter being with potential to be able to be MSA coded for 12 passengers and the potential, subject to contract with the marina, to maintain her current berth at Gunwharf Quays , with direct trains to London 5 minutes from her berth. This is a unique opportunity for a new owner to own a famous head turning sailing boat for a low investment that will both cruise with ease and be competitive at any International classic yacht regatta.She has recently undergone an insurance survey (December 2019) - All recommendations carried out and has had a full hull respray in 2020.
Standing rigging renewed 2010
Cutter headed sloop rig; keel-stepped height 31.50 meters.
Awlgripped white spars (2005).
Sparmaker: Southern Spar Services.
Boom strengthened 2016
Stainless steel standing rigging wire replaced in total in 2010 and rig checked (July/August 2016).
Reckmann furling on genoa (2001 – Fully serviced in 2010).
22mm stainless steel chainplates.
Running backstays in Spectra (2005).
Tensioner on inner stay.
Fredricksen battcar system and track (2000) with stack pack.
Lazyjacks and 2 halyards replaced.
Mainsheet track and traveler, genoa and staysail tracks by S11 France all.
Mechanical Electrical Hydraulic Pump installed for Vang & Backstays (HP Hydraulics 2014)
Boom removed stripped serviced, jigged, some joints ground out and re-welded with stainless strengthening ribs fitted (2014 by Crusader sails) - for use with the new electromechanical Vang pump.
2 x 90 ST Double pedestal (not connected for safety but believed to work); primary Hydraulic 2000, secondary electric.
2 x 65 ST.
2 x 55 ST.
2 x 48 ST.
1 x 55 ST Mainsheet.
1 x 40 ST Main traveler.
3 x 65 ST Halyard.
1 x 66 ST Deck mounted at foot of mast.
1 x 55 ST Reefing on mast.
1 x 46 ST Topping lift on mast.
Assorted winch handles
All winches require service and normal re-commissioning
Hood fully battened mainsail, Vectran, 2000.
Kemp furling genoa (new 2014)
Yankee, 11 oz Dacron, 2008.
Staysail serviced (2005), hanks replaced (2001).
Storm Trysail, 1991.
Storm jib, 1988.
Cruising chute (2013) with snuffer
Crusader Sails genoa Magic Furl (2014) not connected
Rigel Poseidon Pedestal magnetic compass at helm.
Fluxgate electronic compass.
Robertson/Simrad Autopilot with a hydraulic linear drive all completely re-commissioned (2013) by HP Hydraulics.
Raymarine E125 GPS Chartplotter at the nav table (2013).
Raymarine E7 GPS Chartplotter at the steering wheel (2013).
Garmin GPS Map 451 (2013).
Simrad 1515 multidate echo sounder/wind indicator with readouts at helm and companionway.
Navtex JMC NCR 330 with a thermal printer (2005).
Icom VHF at the nav station and 2 handheld VHFs (2005).
Skanti TRP82505 SSB.
Windows PC with Expedition Software.
Mini M satellite phone for voice and data.
Wireless Access Point giving WiFi onboard.
Auxiliary 'Cello' screen fitted to mirror the laptop's display.
Colour HP PSC 2510 printer/fax/copier.
Pulpit, pushpit, guardrails, bathing ladder, boarding gates, mast pulpits, swing-out swimming platform and ladder in transom skirt.
Stainless Davits Fitted 2014 by YCP Endeavour.
2.8m Bofer passerelle (2005 in storage ashore).
Klarenbeke air horn (2001).
Anchoring & Mooring Equipment:
2 x Anchors; main 105lb Bruce/second 105lb.
160m 12mm galvanized chain with 50m 12 mm chain and 25mm warp all stored in newly constructed chain locker (2005); anchors and chain galvanized (2006).
Lofrans Project 2000 24v 200w (2005) and Simpson Lawrence Pacific windlass V4000 rebuilt (2005).
Both windlasses on a custom teak plinth with strengthening beneath deck (2005).
Anchor windlass control with chain counter at the helm (not working).
Cleats have new backing plates (2005).
Transom steps in storage ashore.
COVERS, CANVAS, AND CUSHIONS
Hardtop with side screens to enclose center cockpit.
Cockpit cushions (2006).
Canvas Bimini (new 2013) on stainless supports over the steering wheel.
2 x 8 man liferafts (new 2014) on the transom (need service).
2 x Horseshoe life rings.
12 x Certified lifejackets with strobe lights.
406 Mhz EPIRB.
Engine fire fighting system replaced (2012); Catef Marine Fire FM200 Fire detection & extinguishing system with wireless fire detection 63KRX, wireless smoke and siren system 95DB, wireless panic & emergency flash and sound alarm, manual fire suppression system (system discharge, engine & electrical shutdown, forced ventilation). System serviced 2016.
Alarm system (not connected).
Engine & Gearboxes:
1 x Perkins M215C turbo charged 213hp @ 2,500 rpm diesel (2003).
Serviced Summer 2016
2F twin disc MG506 hydraulic 2:1 reduction gearbox.
Cutlass bearing replaced (December 2019)
MAINTENANCE AND PERFORMANCE:
Engine Hours: approx. 2,500 (March 2020)
Cruising Speed: 7 knots.
Cruising Range: Approx. 2,500nm.
Maximum Speed: 9 knots.
Date of Last Major Overhaul: 2005; engine removed and repainted, turbocharger, fuel injection pump and alternator etc all overhauled.
Exhaust system rebuilt (2005).
Fully serviced and decommissioned (2012).
PROPULSION AND STEERING:
Hydraulic AB9856 3 blade self-feathering bronze propeller.
Throttle control replaced with Rexroth-Bosch Marex Mini SB electronic command unit.
Stainless steel shaft (2005)
GRP inner gland and cutlass bearing (cutlass bearing replaced 2019).
Stuffing box overhauled (2005).
Rope cutter (2012).
Maxpower R300 retractable 20hp bow thruster, powered by PTO from large generator (2005).
Mechanical Whitlock single station steering with large hide covered wheel (replaced 2007) and gutter.
Custom pedestal (2005) with instrument pod to carry bow thruster and micro commander engine controls together with depth, autopilot, Windex, and echosounder readouts and pedestal compass.
The steering was completely rebuilt (2005) with the upper and lower bearings of the rudder blade checked, the main gearbox opened and bearings renewed. The aluminum housing of the planet gear mechanism was renewed also. The steering was overhauled in 2012.
220v Shore power; 2 x 220v generators; DC current is 24v.
Ocean Leopard’s wiring was 80% replaced (2005).
All AC loads are separately fused and there is a totally new switch panel.
All batteries were replaced in 2013 except the generator batteries from 2005
Main engine start
2 x 12v (24v) (2013).
1 x 12v/90 Ah Dryfit gel (2005) .
1 x 12v/120 Ah Dryfit gel (2005).
Deep cycle cell.
8 x 2v (2013)
24 batteries in 2 banks (2013) are located in a battery box under the saloon floor along the centerline.
1 x 24v DC 100 amp Mastervolt for charging house batteries.
1 x 12v DC Newmar PT 25 amp 2 way for generator batteries (2005).
1 x 24v/40Ah.
1 x 24v 80Ah.
Northern Lights M8446K 16 kw 220v generator 16kw/1500 rpm 50 hz with PTO for hydraulic bow thruster (2005); (serviced summer 2016). Approx 1,789 hrs.
Fresh Water & Water Heating System:
Electric water pressure system; all pipework replaced (2005).
220v immersion water heating system replaced (2012) and located in the engine room.
New Digital Watermaker Control panel and electronics 2014.
The bilge of Ocean Leopard is divided into 7 sections - chain locker/forepeak, forward crew cabin, owner’s cabin, forward corridor, engine room, aft corridor, and aft lazarette.
All sections have 24v DC bilge pumps with swan necks discharging overboard. Except for the aft lazarette, all sections have an emergency 1 ½” central bilge drain line with a manifold in the engine room. This manifold is connected to a 220v AC self-priming impeller pump; this will also function as a fire pump and is connected to a separate strainer. The pressure line is led to a fire station next to the engine room door. The system was fitted in (2005).
Total capacity of 3600 litres (792 gallons) in 3 x separate tanks.
Day tank in engine room (Auto Day Tank refill system fitted 2014)
All tanks serviced and fuel lines replaced (2005); tanks cleaned (2012).
Tank material one GRP and one in keel.
Fuel tank gauge.
The total capacity of approx. 2600 liters (572 gallons) in 4 x high-density polyethylene tanks fitted in 2009.
Water tank gauges (New Water and fuel sensors 2014)
Watermaker (working in 2016)
The holding tank system on Ocean Leopard was installed in 2005 (but not connected)
Ocean Leopard has both grey and black water tanks all with odor-proof Gebarit grey water lines and 2 x Rheinstrom GWH 24 PE greywater lift pumps.
Aft in the crew quarters, sink and shower, washing machine and galley are connected to a transfer tank aft the galley sink has the option of discharge overboard or to the grey water tank with a valve.
The greywater of the owner’s and guest showers and sinks are collected in a transfer tank forward.
Air conditioning condenser water is also collected into these transfer tanks.
Both transfer tanks discharge forward via a swan neck arrangement.
All heads discharge into the black water tanks. These tanks are located forward under the forward crew berths.
(All figures approximate)
GRP balsa cored sandwich above the waterline and solid laminate GRP below 12mm to 30mm at the lowest point with synthetic cored transverse GRP frames and longitudinal stringers all hand-laminated.
GRP hardtop fitted by Norman Wright in Brisbane (2000); refurbished and re-awlgripped (2005).
In 2005, beneath the waterline, the old antifouling was removed and the epoxy treatment (2001) found to be sound. 3 coats of Awlgrip Hullguard were added and antifouling coatings made good.
The rudder was also dried and refurbished (2005).
GRP cored, teak-laid replaced in 2001 by Zealandia and all refurbished (2005).
Decks recaulked (2008).
Balsa cored GRP Awlgrip painted (2005).
Teak and stainless steel external trim.
KEEL AND RUDDER:
Steel keel with integral diesel tank and substantial lead bulb.
All keel bolts checked and replaced as necessary (2005)
Ultrasonic anti-fouling system (2013)
All seacocks replaced (December 2019)
Antifouled and anodes replaced (December 2019)
