#54026
China | 2019

McConaghy MC77 for sale

General information

Production
2019
Length
24,08 m / 79,00 ft
Location
China

Description

English

The remarkable MC77 delivers modern style, acres of deck space, up to 5 cabins + crew.
Choose a custom layout to fits your wishes.

Rig

Sloop

TWO RIG OPTIONS AVAILABLE

Standard Rig

Alloy rig from Selden with dyform and rod rigging, conventional boom, painted white or black

Carbon Rig Option

Carbon Rig from Axxon with Kevlar standing rigging, Canoe V-Boom, Harken Switch track and mast step.

Clear carbon finish or painted.

WINCHES/SAIL CONTROLS

4 x Harken 80.3 STEP 24VDC Electric

2 x Harken 80.3 STEP 24VDC Electric Spinnaker winches

1 x Performa 3 Speed Alum self-tailing for halyards at mast

1 x 50.2 STEP 24VDC Electric Traveller winch

Harken headsail furler

Clutches for Mainsail & Jib halyards & sheets

Running rigging and fittings for mainsail and headsail

INTERIOR and NAVIGATION LIGHTING and DC POWER

CZone DC Digital Switching System including touch screen, ipad compatible, voltage, tank, bilge and fuse alarms, lighting (switches

and dimmers), custom controls for centreboards and hydraulic transom (optional)

All internal lights are LED

Reading lights x 8

Down lights x 42

Cockpit Lights x 8

Courtesy lights x 10

1 Red/White Nav Stn Light (Hella 2XT 959 510 851)

1 All round white nav.light (Hella 2LT 980 960-001)

1 Stern light (Hella 2LT 959 909-001)

1 Port light (Hella 2LT 959 900-001)

1 Stbd light (Hella 2LT 959-908-001)

1 Masthead light (Hella 2LT 959 940-201)

1 Tank Sensor Monitor

ENTERTAINMENT

Fusion system with four speakers

PLUMBING

4 - Rule automatic bilge pumps (2,000 GPM each )

2 - Henderson MK 5 Universal Manual Bilge pump

Pressurized hot & cold water system

6 - Electric toilets

2 - Isotherm water heaters – 40 Liter tanks slim

2 - Whale Universal Pressure pump 18 L/M 45 PSI

Black water tanks capacity TBD

Fresh water tanks approx 1,600 L

Fresh Water Level Sensor

Holding tank sensor

Plumbing for Air Con and watermaker pre-fit

RUDDERS AND STEERING

Balanced spade rudders

Self aligning bearings

Hydraulic steering

Emergency tiller

DECK HARDWARE

Lewmar flush hatches

Clear carbon composite stanchions with stainless steel and dyneema lifelines

Recessed coachroof handrails in clear carbon

Foredeck trampolines - dyneema

Deck fittings for Fuel, Water, Black water pump out

ANCHORING & MOORING

Lewmar V8 electric windlass

40kg anchor, 80m chain, 30m warp

6 Seasmart 200mm folding cleats

PROPULSION

Two 160 HP Yanmar engines

Sail Drive and feathering propellers

Single electronic throttle control mounted to starboard helm

Engine instrument panel at helm position

Fresh water engine cooling system

Exhaust waterlocks

Water separator

Exhaust muffler

FUEL

Two Fuel tanks in total approx. 460 liters

Racor 500 fuel filters

Two Fuel Level Sensors

Two Deck Fillers

Insulation in Engine rooms

ELECTRICAL

AC Switch panel

Shorepower cables

Combination inverter

24 VDC Supply

Galvanic Isolator

Two 150 amp 24V alternators

800 amp/hour AGMhouse batteries

Two 105 amp/hour AGM engine start batteries

DESIGN

Naval Architect: Ker Yacht Design

Interior Design: Design Unlimited

Composite Engineering approved by Bureau Veritas

Certificate CE

PRINCIPAL DIMENSIONS

LOA 24.00 m

LWL 23.10 m

Max Beam 10.50 m

Draft 1.20 m - 5.10 m

Height of Mainsail (above DWL) 39.6 m

Upwind Sail Area 376 sq. m

CONSTRUCTION

Built using a controlled vacuum infusion process and pressed panels of E-glass, carbon composite and Corecell.

Providing lightweight, strength and rigidity.

Composite centerboards

Carbon composite longeron with integrated anchoring system

Frameless bi-folding doors with tempered safety glass between saloon and aft deck

Carbon stairs and handrails to fly bridge.

FINISH

Hull, deck and superstructure painted in high quality two part polyurethane (White standard)

Non-skid areas on side decks and coachroof

Flush Lewmar deck hatches

Below waterline finished with epoxy primer

$ 5 345 000
