HULL & DECK CONSTRUCTION

HAND LAID GRP CONSTRUCTION USING WOVEN ROVINGS AND CHOP STRAND MAT

WITH INTEGRAL STIFFENING

SOLID FIBERGLASS HULL BOTTOM

STRINGER WITH FOAM CORED REINFORCEMENT

HULL STIFFENED WITH LONGITUDINAL STRINGERS SUPPORTED BY TRANSVERSE

BULKHEADS AND DECKS

LILLY OR EQUIVALENT GEL COAT

NAVY BLUE COLOURED STRIPES AS G.A. DRAWING

HULL ANTIFOULED WITH BOTTOM PAINT

RUDDER PLATE ANTIFOULED

TEAK SIDE DECKS, FOREDECK AND AFT DECK

NON-SKID FORWARD COACH ROOF

HULL AND DECK FITTINGS

ALL EXTERIOR FITTINGS AND HARDWARE IN STAINLESS STEEL

STAINLESS STEEL OPEN ABLE PORTHOLE WITH FLY SCREEN

STAINLESS STEEL FOREDECK HATCH (ESCAPE HATCH SIZE)

TWIN LARGE TRANSOM PORTHOLE (ESCAPE HATCH SIZE)

PORTHOLE INSERTS FITTED SO WATER RUNS OUTBOARDS, NOT INTO BOAT WHEN

PORTHOLES ARE OPENED

REMOVABLE STAINLESS STEEL FLAG POLE ON BOW RAIL _

1-1/4" ROUND TYPE HAND RAIL WITH 1" STANCHIONS FOR MAIN DECK AS G.A.

DRAWING

STAINLESS STEEL ROUND PULPIT

STAINLESS STEEL FENDER RACKS (6)

DECK SUPERSTRUCTURE BOLTED AND BONDED TO HULL ALONG BULWARK LINE,

WITH THE JOINT CAPPED IN STAINLESS STEEL

FULL PERIMETER STAINLESS STEEL RUBBING RAIL

(6) STAINLESS STEEL FAIRLEADS - (2) AT BOW AND (4) AT AFT DECK

(4) STAINLESS STEEL CROSS BOLLARD - (2) AT BOW AND (2) AT AFT DECK

(4) STAINLESS STEEL CLEAT - (4) AMIDSHIPS

((2) TRANSOM CLEATS _

RUB STRAKES ON BOW

FUEL AND FRESH WATER DECK FILLERS

FRESH WATER DECK WASH POINTS ONE IN AFT DECK ONE IN ANCHOR LOCKER

SEA WATER DECK WASH POINTS ONE IN AFT DECK ONE IN ANCHOR LOCKER

KSE STANDARD HI QUALITY STAINLESS STEEL DOOR HINGES AND LATCHES

(4) SIDE DECK LIGHTS; (2) PER SIDE

NAVIGATION LIGHTS: PORT, STARBOARD, STEAMING, STERN AND ANCHOR

AIR HORN

FRAMELESS SIDE WINDOWS

CLEAR SAFETY GLASS FOR PILOT HOUSE WINDSHIELDS

CLEAR GLASS FOR SIDE WINDOWS

FLY BRIDGE

DESIGN PER G.A. DRAWING

LOCKER IN FLY BRIDGE CONSOLE _

FIBERGLASS HELMSMAN CHAIR WITH WHITE VINYL CUSHION

FLY BRIDGE SEAT UNITS WITH WHITE VINYL CUSHIONS AND STOWAGE UNDERNEATH

(1) STAINLESS STEEL HAND RAIL ON SEAT BACK OF AFT FLY BRIDGE SEAT

FIBERGLASS HOOP MAST AS G.A. DRAWING FOR MOUNTING RADAR AND ANTENNA

STAINLESS STEEL ANCHOR LIGHTS BRACKET

LEXAN TINTED WINDSCREEN WITH STAINLESS STEEL SUPPORTS

STAINLESS STEEL HANDRAIL AROUND FLY BRIDGE _

10" STAINLESS STEEL HANDRAILS AROUND CANOPY _

STAINLESS STEEL STEPS WITH HAND RAIL AND TEAK TREADS FOR ACCESS FLY

BRIDGE FROM AFT DECK

MANSHIP ALUMINUM TYPE GLAZED HATCH

NON-SKID FLY BRIDGE DECK

(2) LOWER LEVEL FLY BRIDGE LIGHTING _

DRINK LOCKER WITH DRAIN _

CUP AND BOTTLE HOLDERS _

BUILT IN AFT DRAIN TO WATER LINE

FLY BRIDGE HELM

INSTRUMENT CONSOLE

HYDRAULIC POWER STEERING

HIGH QUALITY STAINLESS STEEL STEERING WHEEL

MAPD ENGINE INSTRUMENT

ENGINE CONTROL

WINDLASS CONTROL

HORN CONTROL

SWITCH FOR LIGHTS _

(1) 12V ACCESSORY SOCKET _

(1) AC POWER POINT _

AFT DECK

FIBERGLASS AFT DECK CANOPY WITH LOCKABLE DOOR TO FLY BRIDGE AND

STAINLESS STEEL SUPPORTS _

LOWER PROFILE 10" STAINLESS STEEL GRAB RAILS ON AFT DECK CANOPY

DODGER PANELS AT PORT, STBD AND AFT OF AFT DECK

TRANSOM WET BAR WITH CORIAN COUNTER TOP FOR OWNER SUPPLIED BBQ AND

FRIDGE _

SELF-DRAINING AFT DECK

PORT SIDE TRANSOM STAIRWAY WITH TEAK STEPS AND LIGHTS FOR ACCESS SWIM

PLATFORM FROM AFT DECK _

STAINLESS STEEL GRAB RAIL FOR TRANSOM STAIRWAY

FIBERGLASS TRANSOM GATE FROM AFT DECK TO BATHING / SWIM PLATFORM

(1) FRESH WATER WASH DOWN OUTLET

(1) SEA WATER WASH DOWN OUTLET

OVERHEAD LIGHTING

(2) TELESCOPIC BOAT HOOK _

TEAK ENSIGN STAFF WITH STAINLESS STEEL BASE _

SWIM / BATHING PLATFORM

HAND RAIL ACROSS TRANSOM

NON-SKID FINISH BATHING PLATFORM

BUILT IN SHOWER CABINET WITH WHALE HOT AND OLD WATER HAND-HELD

SHORE POWER CABINET _

UNDER MOUNTED BOARDING / SWIMMING LADDER

MAIN HELM STATION

HELM CONSOLE FOR MOUNTING ACCESSORIES

BLACK BURL HELM CONSOLE PANEL

HELM SEAT WITH STOWAGE UNDERNEATH AND CHOICE OF LEATHER _

HELMSEMAN SEAT WITH STOWAGE UNDERNEATH AND SAME LEATHER UPHOLSTERY

AS SALON SOFA _

HYDRAULIC POWER STEERING

HIGH QUALITY STEERING WHEEL

MPD ENGINE INSTRUMENT

ENGINE CONTROL

GENERATOR REMOTE START / STOP

WINDLASS CONTROL

HORN CONTROL

NAVIGATION LIGHTS BREAKER SWITCH

ENGINE ROOM FAN SWITCH

SEA FIRE FIRE EXTINGUISHER ALARM AND TEST PANEL

BILGE PUMP CONTROLS WITH INTEGRAL OPERATING WARNING LIGHTS AND AUDIBLE

ALARMS

HOLDING TANK INDICATOR

MAGNETIC COMPASS OR EQUIVALENT

FUEL GAUGES

MASTER ELECTRIC CONTROL PANEL WITH AC AND DC CIRCUIT BREAKERS

3 VARIABLE SPEED WINDSCREEN WIPERS (PANTOGRAPH TYPE) WITH WASHER

(1)(1) OPENING DOOR TO SIDE DECK

ANCHOR, MOORING & TENDER EQUIPMENT

BOW PLATFORM WITH FRP BASE

ELECTRICAL FORWARD LAUNCH SINGLE ANCHOR SYSTEM

(1) ELECTRICAL WINDLASS

WINDLASS FOOT SWITCH AT BOW

WINDLASS REMOTE AT PILOT HOUSE AND FLY BRIDGE HELM

(1) 60 LBS (27 KG) CQR TYPE ANCHOR

229 FT (70m) 3/8" BBB ANCHOR CHAIN

ANCHOR ROLLER & CHAIN STOPPER _

(1) ANCHOR LOCKER HATCH

PRE-WIRE FOR OWNER SUPPLIED ELECTRIC CRANE _

STERN GEAR

STERN GEAR

HEAVY DUTY STAINLESS STEEL SUS630 SHAFTS

BRONZE P TYPE SHAFT STRUTS

HI QUALITY SHAFT BEARING

HI QUALITY SHAFT LOG SEAL

STAINLESS STEEL RUDDER

RUDDER STOCK

HI QUALITY RUDDER STOCK BEARING

FRP STERN TUBE

3 BLADE NICKEL ALUMINUM BRONZE PROPELLERS

TRANSOM MOUNTED ANODES, BONDED TO ALL MAJOR UNDERWATER FITTINGS

STEERING SYSTEM

TELEFLEX OR EQUIVALENT HYDRAULIC POWER STEERING SYSTEM

EMERGENCY TILLER

ZF CRUISE COMMAND ELECTRONIC ENGINE CONTROL SYSTEM WITH (2) MC-2000-2

ELECTRONIC THROTTLE CONTROLS

STABILIZER AND THRUSTER SYSTEM

ENGINE AND DRIVE TRAIN

TWIN CAT C-7 ACERT 460 HP DIESEL ENGINE WITH ZF MARINE GEAR BOX _

FRESH WATER COOLED ENGINE, THROUGH SEA WATER

RACOR FUEL FILTER AND WATER SEPARATOR FOR ENGINES

UNDER WATER EXHAUST SYSTEM

HALYARD EXHAUST OVER HEAT ALARMS (HMI) FOR STD ENGINES _

ENGINE ROOM

LOCATED UNDER THE WHEELHOUSE SOLE, WITH LARGE REMOVABLE FLOOR

PANELS THAT GIVE CLEAR ACCESS FOR MAJOR SERVICE

WELL PLANNED ENGINE ROOM

FIBERGLASS BONDED TO HULL ENGINE BEDS WITH ENGINE LOAD DISTRIBUTED ON

BLACK MILD STEEL CHANNELS FOR STRENGTH AND VIBRATION ABSORPTION

WATERTIGHT BULKHEADS

SOUND AND HEAT INSULATION - BULKHEAD (1 LAYER) AND CEILING (1 LAYER)

WHITE FRP DIAMOND FLOOR PLATES

STAINLESS STEEL SUPPORT FOR SALOON FLOOR

NATURAL VENTILATION THROUGH TOPSIDE GRILLS, WITH NATURAL AND FORCED

EXTRACTION SYSTEMS

ENGINE ROOM EXTRACTOR FANS

EMERGENCY AIR INTAKE AND EXTRACTION SHUT OFF

FRESHWATER FILL HOSE FOR ENGINES AND GENERATORS

A HINGED HATCH ON GAS STRUTS WITH STAINLESS STEEL FOLDING LADDER TO

ACCESS ENGINE ROOM FROM MAIN SALOON _

AFT ACCESS HATCHES PROVIDED BEHIND THE COMPANIONWAY STAIRS

DUPLEX RECEPTACLES

LED OVERHEAD LIGHTING

ELECTRICAL SYSTEM

ELECTRICAL SYSTEM

AC 220V 50HZ ELECTRICAL SYSTEM

COLOR CODED WIRING FOR EASY IDENTIFICATION

(1) 200 AH WET CELL BATTERIES EXCLUSIVELY FOR ENGINE START

(1) 120 AH WET CELL BATTERIES FOR GENERATOR START;

(2) 200 AH WET CELL BATTERIES FOR DC 12V DOMESTIC SERVICE

ENCLOSED ACID-PROOF FIBERGLASS BATTER BOX WITH COVER AND VENT HOSE

BATTERY SELECTOR SWITCHES

EMERGENCY BATTERY COUPLING SYSTEM PERMITS EACH ENGINE TO START FROM

DOMESTIC SERVICE BATTERY BANK

(2) BATTERY CHARGERS _

(1) ONAN e-QD 9.5 Kw / 50 Hz SINGLE PHASE GENERATOR WITH SOUND SHIELD,

RACOR FILTER, MUFFLER AND GAS & WATER SEPARATOR

MAIN ELECTRICAL PANEL INCLUDES SEPARATE AC POWER CONTROL AND AC

CIRCUIT BREAKER PANEL

DC 12 VOLT DC MONITORING & MAIN CIRCUIT BREAKER PANEL

(1) 30 AMP SHORE POWER INLET AT TRANSOM

DC 12V LIGHTS THROUGHOUT

HIGH QUALITY LIGHT SWITCH

HIGH QUALITY AC SOCKETS

SEAWATER SYSTEM

HIGH QUALITY SEA WATER STRAINERS FOR ALL SEA WATER INLETS

SEA COCKS TO ALL UNDERWATER FITTINGS

BRONZE THROUGH HULL FITTINGS WITH GATE VALVE

(1) DECK WASH DOWN PUMP FOR SEA WATER

FRESH WATER SYSTEM

170 US GALLONS (750 LITERS) OF FRESH WATER IN GRP WATER TANK _

WATER LEVEL SIGHT GAUGE _

ELECTRIC GAUGE IN GALLEY _

DECK FILL FOR FRESH WATER TANK

(1) CITY / SHORE WATER INLET WITH PRESSURE REGULATOR

KITEC FRESH WATER PIPE LINE

(1) JABSCO ULTRA-MAX 12V DC WATER PRESSURE SYSTEM WITH PUMP, PRESSURE

SWITCH, ACCUMULATOR TANK AND PUMPGARD STRAINER OR EQUIVALENT

(1) TORRID 20 GAL OR EQUIVALENT HOT WATER HEATER

WATER WILL ALSO BE HEATED BY ENGINE COUPLED CALORIFIER _

BLACK AND GRAY WATER SYSTEM

45 US GALLONS (170 LITERS) OF FRP HOLDING TANK

MACERATOR PUMP FOR HOLDING TANK

Y VALVE FOR DOCKSIDE PUMP OUT FROM HOLDING TANK

DIRECT DECK DISCHARGE FOR HOLDING TANK

HOLDING TANK LEVEL GAUGE AND SWITCH FOR DECK PUMP OUT NEXT TO LOWER

HELM STATION

SMELL FILTER FOR HOLDING TANK

(2) JABSCO QUIET-FLUSH OR EQUIVALENT ELECTRICAL TOILET WITH CONTROL

PANELS FOR HEADS _

SUMP PUMPS IN INDEPENDENT SUMP TANKS

(2) SUMP TANK WITH INSPECTION HATCH

AIR CONDITIONING AND HEATING SYSTEM

EMERGENCY &

INTERIOR FURNISHINGS GENERAL

LAYOUT PER G.A. DRAWING

SUPERYACHT JOINERY DETAILING _

TEAK WOOD VENEER FINISH THROUGHOUT

TEAK TIMBER TRIM

SATIN WOOD VENEER FINISH

CHROME PUSH / PULL LATCHES

CHROME DOOR HANDLE

RUBBER PROFILES IN STEPS

FIRE PROOF FOAM FOR ALL CUSHIONS AND MATTRESS

FABRIC FOR BED SPREAD, BED HEAD, CURTAIN AND SEATING

MAIN SALOON

LAYOUT AS G.A. DRAWING

WOOD VENEER WALL PANELING AND BULKHEAD

STORAGE CABINETS WITH VARNISHED VENEER TOP

CHART TABLE AND BOOKCASE FORWARD _

BAR UNIT UNDER HELM SEAT AND BOTTLE STOWAGE AFT _

TELEVISION CABINET FOR OWNER SUPPLIED TELEVISION

LEATHER SOFA WITH STORAGE; CHOICE FROM YEARD SAMPLE BOOK _

TWO SEATER FREE STANDING ARM CHAIR IN LEATHER _

(1) HI/LOW TEAK SALOON TABLE WITH REMOVABLE TAPE TOP _

SYNTHETIC TEAK WITH WHITE INLAYS FLOOR

CLEAR SIDE WINDOWS

STAIR CASE AND DOOR TO AFT DECK

FIXED STAIR TO FORWARD CABINS WITH STORAGE UNDER _

HINGED STAIR TO AFT CABIN WITH ENGINE ROOM ACCESS _

WHITE VINYL HEADLINER PANEL WITH OVERHEAD LIGHTING

LIGHTS SWITCHES

AC POWER SOCKETS

GALLEY AREA

LAYOUT AS G.A. DRAWING

WOOD VENEER WALL PANELING AND BULKHEAD

STORAGE CABINETS WITH DRAWERS AND OVERHEAD LOCKERS

CHOICE OF GRANITE, MARBLE OR CORIAN WORK TOP AND BACK SPLASH FROM

YARD SAMPLE BOOK

STAINLESS STEEL GALLEY SINK

CHROME SINK FAUCET

INSTALL OWNER SUPPLIED FRIDGE FREEZER / HOB / OVEN AND GALLEY BLOWER

BOTTLE RETAINING FIDDLE

STAINLESS STEEL PAN RESTRAINT

SYNTHETIC TEAK WITH WHITE INLAYS FLOOR

WHITE VINYL HEADLINER PANEL

LIGHT SWITCHES

AC POWER SOCKETS

FRESH WATER LEVEL GAUGE

MASTER STATEROOM (AFT)

LAYOUT AS G.A. DRAWING

WOOD VENEER OR WHITE VINYL WALL PANELING AND BULKHEAD

STORAGE CABINET WITH DRAWERS AND WOOD VENEER TOP

LARGE DOUBLE BED WITH SPRUNG MATTRESS

UPHOLSTERED HEADBOARD _

STORAGE UNDER BED

BOOKCASE AND LOCKERS OVER BERTH _

(2) READING LAMPS

DRESSING TABLE WITH MIRROR

(1) STOOL _

CEDAR-LINED WARDROBE WITH LIGHT

SYNTHETIC TEAK WITH WHITE INLAYS FLOOR _

OPENING PORTHOLES

WHITE VINYL HEADLINER PANEL WITH OVERHEAD LIGHTING

LOW-LEVEL ROPE LIGHTING UNDER THE BED AND BEHIND VALANCES, PORT AND

STBD

LIGHTS SWITCHES

AC POWER SOCKETS

(1) FULL LENGTH MIRROR

MASTER BATHROOM (AFT)

LAYOUT AS G.A. DRAWING

DIRECT ACCESS FROM MASTER STATEROOM

WHITE FORMICA WALL PANELING, BULKHEAD AND CABINETS WITH TEAK TRIM

STORAGE CABINET WITH MIRROR

WASHBASIN AND CHOICE OF GRANITE OR MARBLE TOP

CHROME SINK FAUCET

SYNTHETIC TEAK WITH WHITE INLAYS FLOOR

PORTHOLE WITH TEAK VENETIAN BLIND

BOEING HEADLINER PANEL

(1) TOWEL RAIL

(1) TOILET

(1) EXTRACTOR FAN

LIGHTS SWITCHES

AC POWER SOCKET

WALK-IN SHOWER

CHROME SHOWER MIXER

WHITE FORMICA SHOWER STALL

NON-SKID SHOWER FLOOR

ITAL FOLDING SHOWER DOOR WITH LOCK

VIP STATEROOM

LAYOUT AS G.A. DRAWING

WOOD VENEER OR SELECTED WHITE VINYL WALL PANELING AND BULKHEAD

STORAGE CABINET WITH DRAWERS AND WOOD VENEER TOP

TWIN BED WITH FOAM MATTRESS _

UPHOLSTERED HEADBOARD _

STORAGE UNDER BED

(2) READING LAMPS

CEDAR-LINED WARDROBE WITH LIGHT

SYNTHETIC TEAK WITH WHITE INLAYS FLOOR _

OPENING PORTHOLES

OCEAN AIR BLIND FOR OVERHEAD ACCESS HATCH

WHITE VINYL HEADLINER PANEL WITH OVERHEAD LIGHTING

LIGHTS SWITCHES

AC POWER SOCKETS

(1) FULL LENGTH MIRROR

VIP / DAY BATHROOM

LAYOUT AS G.A. DRAWING

DIRECT ACCESS FROM VIP STATEROOM OR HALLWAY

WHITE FORMICA WALL PANELING, BULKHEAD AND CABINETS WITH TEAK TRIM

STORAGE CABINET WITH MIRROR

WASHBASIN AND CHOICE OF GRANITE OR MARBLE TOP

CHROME SINK FAUCET

SYNTHETIC TEAK WITH WHITE INLAYS FLOOR

PORTHOLE WITH TEAK VENETIAN BLIND

BOEING HEADLINER PANEL

(1)TOWEL RAIL

(1) TOILET

(1) EXTRACTOR FAN

LIGHTS SWITCHES

AC POWER SOCKET

WALK-IN SHOWER

CHROME SHOWER MIXER

WHITE FORMICA SHOWER STALL

NON-SKID SHOWER FLOOR

ITAL FOLDING SHOWER DOOR WITH LOCK

PORT STATEROOM

LAYOUT AS G.A. DRAWING

WOOD VENEER OR SELECTED WHITE VINYL WALL PANELING AND BULKHEAD

UPPER AND LOWER BUNK WITH FOAM MATTRESS

STORAGE UNDER BED

NIGHT STAND WITH DRAWERS AND WOOD VENEER TOP

(2) READING LAMPS

CEDAR-LINED WARDROBE WITH LIGHT

SYNTHETIC TEAK WITH WHITE INLAYS FLOOR _

OPENING PORTHOLE

SKYLIGHT WITH SLIDING COVER

WHITE VINYL HEADLINER PANEL WITH OVERHEAD LIGHTING

LIGHTS SWITCHES

AC POWER SOCKETS

CE MARK CERTIFICATION _

CE CERTIFICATION _

(1) ALUMINUM CE NAME PLATE ON PORT SIDE OF SALOON DOOR _

OTHER ITEMS SUPPLIED AS STANDARD

DOCKSIDE SHORE TELEVISION / TELEPHONE CONNECTION

CLOSED CELL FOAM AND MESH BASE CONSTRUCTION FOR ALL EXTERIOR SEATING

FLY SCREEN FOR ALL OPEN ABLE PORTHOLE
